Turtle Siltblok 300TE Series Silt Filtration System with 110mm Connections

Code:
PARENT-TURTLE-SB300TE
Brand:

This item is out of stock and not available to purchase.

The Siltblok SB300TE is a pre-assembled silt filtration chamber designed to effectively manage sediment in drainage systems. Featuring a 300mm diameter, it uses a 100% recycled thermoplastic block to filter out total suspended solids, including silt up to 0.03mm and has a LLDP... Read More

Create a wishlist

"Terram roll"

Bryn A Oakley

Description

The Siltblok SB300TE is a pre-assembled silt filtration chamber designed to effectively manage sediment in drainage systems. Featuring a 300mm diameter, it uses a 100% recycled thermoplastic block to filter out total suspended solids, including silt up to 0.03mm and has a LLDPE chemical and impact resistant base.

This model includes 110mm main channel socket connections and optional side inlets, ensuring flexible installation. With a 7.5kg capacity basket and flow rates up to 6 litres per second, it is suitable for various applications, providing reliable and efficient sediment management.

Features & Benefits: Turtle Siltblok 300TE Series Silt Filtration System with 110mm Connections

  • Main Channel Pipework - 110mm Single wall EN 1401 outlet at 0 degrees and inlet at 180 degrees
  • Optional Side Inlets - 110mm Single wall EN 1401 inlets at 90 and 270 degrees
  • 340mm sump depth

Dimensions

Depth 1.02m
1.52m
1.99m

Details

Material Plastic Product Type Silt Trap Diameter 300mm
