Ventilation Plenum Box 100mm x 63mm with 2 Ports - Lindab Indomo PVCU

Code:
885376
Brand:
Free UK Delivery

This item is out of stock and not available to purchase.

Dimensions Main Diameter : 100mm Port Diameter : 63mm Length : 206mm Width : 206mm Height : 68mm Description The plenum box is intended for supply and exhaust air. It is intended to accommodate a valve. It is designed for ceiling installation but can be used at othe...Read More

Create a wishlist

"Very happy"

Kenny Brown, Ayr

Description

Dimensions
Main Diameter : 100mm
Port Diameter : 63mm
Length : 206mm
Width : 206mm
Height : 68mm


Description

The plenum box is intended for supply and exhaust air. It is intended to accommodate a valve. It is designed for ceiling installation but can be used at other locations as well.

All types have Ø 63 mm studs with Lindab Safe sealings for connections of either SR 63 spiral-seamed duct or semiflexible duct LFPE. Each Ø 63 connection is equipped with a clip to hold the semiflexible duct LFPE – Smart lock function.

Fulfils the requirements for air tightness class D.

The shown pressure drop is for the box alone, which means that the pressure drop for the valve has to be added.

Details

Diameter 100mm Ports 2 Ports Port Diameter 63mm
