Ventilation Manifold 125mm x 76mm with 3 Ports - Lindab Indomo MHU

Code:
116387
Brand:
Free UK Delivery

Dimensions Main Diameter : 125mm Port Diameter : 76mm Length : 321mm Width : 184mm Height : 138mm Description The manifold can be used for both supply and exhaust air. It is available in several types and dimensions. All types have Ø 63 or Ø 80 mm ... Read More

Create a wishlist

"Good value"

James

Description

Dimensions
Main Diameter : 125mm
Port Diameter : 76mm
Length : 321mm
Width : 184mm
Height : 138mm

Description
The manifold can be used for both supply and exhaust air. It is available in several types and dimensions. All types have Ø 63 or Ø 80 mm studs with Lindab Safe sealings for connections of SR spiral-seamed ducts or semiflexible ducts LFPE. Use the transition piece RCFU, with integrated Smart Lock function, to connect the LFPE 76/90-dimension to InDomo manifolds and plenum boxes. The manifolds are designed for floor installation but can be used everywhere, also in the ceiling for example.

The smart lock function allows you to fasten LFPE effortlessly to the Safe studs.

Two turnable anchor plates, placed on the bottom of the manifold, can be used for fixation.

Fulfills air tightness class D.

Dimensions

Length
138mm
Depth
184mm
Width
270mm

Details

Diameter
125mm
Ports
3 Ports
Port Diameter
76mm
