ACO Raindrain Driveway Channel Drain 1m x 118mm x 97mm - B125

Code:
47001
Brand:

Manufactured from Vienite, ACO's high-strength recycled polymer concrete, this ACO RainDrain B125 Driveway Channel Drain will ensure an effective channel drainage solution for light-duty pedestrian applications, such as driveways and small private car parks. The channel com...Read More

There are other items you may need to complete your project, please make your selections below:

£37.20 Incl. VAT
Was: £40.00 Incl. VAT
You save: £2.80 Incl. VAT (excluding addon products)
Oops! Please select from the options
Est. Delivery: 1-2 Working Days
Shipping costs displayed in basket.
We can let you know when this product is back in stock.

This product is proving to be very popular and has unfortunately sold out.

Enter your email below and we'll notify you as soon as this product is back in stock:

For delivery Wednesday, May 29th - order in:
days hrs mins secs
Subject to stock availability, if products on a 24 hours service are ordered alongside products NOT on a 24 hours service, this may delay your whole order.
View Transport Policy

All delivery charges are included in the final shopping basket and are dependent on the products Scottish Highlands & the Islands where additional shipping charges will apply.

Please note that not all products will incur an additional delivery charge to the Scottish Highlands & the Islands – this is based on the costs from the manufacturer, distributor or courier providing shipping on our behalf. If your delivery address is in the Scottish Highlands and Islands, a member of our helpline team will contact you prior to processing your order should an additional delivery charge apply.

While we make every effort to ensure orders are delivered by the date required, we cannot guarantee availability from the manufacturer or the manufacturer's delivery schedules.

Any variation to web delivery date given will be advised to you by email or telephone. If we are unable to make delivery because access is not possible, we reserve the right to make a failed delivery charge.

Create a wishlist

"Drainage channels"

David Jones

Description

Manufactured from Vienite, ACO's high-strength recycled polymer concrete, this ACO RainDrain B125 Driveway Channel Drain will ensure an effective channel drainage solution for light-duty pedestrian applications, such as driveways and small private car parks.

The channel comes with a cast iron Heelguard™ ATec grating, providing a stylish and modern finish to your drainage system, whilst also ensuring a safe surface on which to walk, even in high heels.

Features & Benefits: ACO Raindrain Driveway Channel Drain 1m x 118mm x 97mm - B125

  • Will ensure an effective channel drainage solution for light-duty pedestrian applications
  • Manufactured from Vienite, a high-strength recycled polymer concrete
  • Comes with a cast iron Heelguard™ ATec grating
  • B125 weight load class, suitable for areas with light vehicular use and low traffic
  • Lightweight design makes it easy to handle
  • Simple knock-out sections makes connecting to pipes easy
  • Clip-locking design allows you to connect channels together
  • In-built sealant groove will provide a secure watertight installation
  • Unique shape helps to anchor the channel to the concrete surround
  • Improved flow rate within channel also helps to promote self-cleansing

The RainDrain channel's lightweight design makes it easy to handle when manoeuvring it into position. The simple knock-out sections and clip-locking design featured on the channel mean installation is quick and hassle-free, and the in-built sealant groove will provide a secure watertight installation.

Its unique shape helps to anchor the channel to the concrete surround, ensuring a sturdy and reliable installation. The channel's profile also helps to improve the flow rate of water flowing through the system, which also helps to promote self-cleansing, reducing the risk of blockages building up over time.

Standards & Certification

  • British/European Standard: BS EN 1433: 2002

Please note:

  • This slot channel is not suitable for threshold drainage applications.

Dimensions

Length 1m Depth 97mm Width 118mm

Details

Material Cast Iron Product Type Channel Base and Grate Range RainDrain Load Rating B125

Questions & Answers

Question:

does it come with end caps

Answer:

No it does not. The product codes for the end caps are:

Closing end cap - 319288

Outlet end cap - 319289

Question:

can you advise the reference number for a replacement black grill ?

Answer:

The product code for the grating only is: 20400. Please note, these come in 500mm lengths.

Question:

Can I fit 110mm drain as horizontal outlet rather than underneath?

Answer:

Yes you can using product code 319289

Question:

Can you supply the B125 cast iron grating without the drainage channel?

Answer:

Yes, you can get them using product code 20400

Question:

Is there a variant of this where the water outlet is positioned sideways rather than at the end of the channel (so that a perpendicular pipe in the middle of the channel can be connected)?

Answer:

I am afraid these can only be drained Horizontally from the end or vertically from the end. There is no centre side option

Question:

What products do I need to: 1) seal one end, and 2) connect to a French drainage system at the other end.

Answer:

Closing End Cap
Product code: 319288



Outlet End Cap

Product code: 319289



Bottom Outlet Connector

Product code: 0056





Question:

What is the best procedure on how to cut Chanel down?

Answer:

On concrete channels an angle grinder would be the best option

Question:

Could you advise flow capacity for the ACO Raindrain driveway channel drain 1m x 118mm x 97mm - B125 when laid at a 1:100 slope?

Answer:

The overall channel length has an effect on the flowrate of the channel. If you could email the length of the channel being installed to sales@drainagesuperstore.co.uk - we will be able to advise further.
