ACO Raindrain Domestic Channel Drain 1m x 118mm x 97mm - A15

Code:
47000
Brand:

Perfect for surface water drainage in a variety of domestic and light-duty traffic applications, this ACO RainDrain Domestic Channel Drain is lightweight and versatile. The high-quality channel drain has been crafted from Vienite, ACO's own recycled polymer concrete, for stren...Read More

There are other items you may need to complete your project, please make your selections below:

£17.50 Incl. VAT
Oops! Please select from the options
Est. Delivery: 1-2 Working Days
Shipping costs displayed in basket.
We can let you know when this product is back in stock.

This product is proving to be very popular and has unfortunately sold out.

Enter your email below and we'll notify you as soon as this product is back in stock:

For delivery Tuesday, Feb 27th - order in:
days hrs mins secs
Subject to stock availability, if products on a 24 hours service are ordered alongside products NOT on a 24 hours service, this may delay your whole order.
View Transport Policy

All delivery charges are included in the final shopping basket and are dependent on the products Scottish Highlands & the Islands where additional shipping charges will apply.

Please note that not all products will incur an additional delivery charge to the Scottish Highlands & the Islands – this is based on the costs from the manufacturer, distributor or courier providing shipping on our behalf. If your delivery address is in the Scottish Highlands and Islands, a member of our helpline team will contact you prior to processing your order should an additional delivery charge apply.

While we make every effort to ensure orders are delivered by the date required, we cannot guarantee availability from the manufacturer or the manufacturer's delivery schedules.

Any variation to web delivery date given will be advised to you by email or telephone. If we are unable to make delivery because access is not possible, we reserve the right to make a failed delivery charge.

Create a wishlist

SUPER SALE 5% off all orders over £500 ex VAT

USE CODE: SUPER5
CODE COPIED
Ends: 29 Feb 2024 23:59

Description

Perfect for surface water drainage in a variety of domestic and light-duty traffic applications, this ACO RainDrain Domestic Channel Drain is lightweight and versatile. The high-quality channel drain has been crafted from Vienite, ACO's own recycled polymer concrete, for strength and reliability.

With a galvanised steel grating that is visually appealing and withstands corrosion, this channel drain has been UKCA and CE marked and fully certified to BS EN 1433:2002 with an A15 load class, making it ideal for use on domestic drives, pedestrian areas, patios, paths, block paving and garage thresholds.

Features & Benefits: ACO Raindrain Domestic Channel Drain 1m x 118mm x 97mm - A15

  • Galvanised steel grate withstands corrosion
  • Includes a knock-out for connection to a 110mm PVCu pipe
  • Easy to install with interlocking
  • A15 load class for light vehicular traffic and pedestrian areas
  • Accessories available for quick and professional installations
  • Channel form secures into a concrete surround
  • High-quality and lightweight
  • 1000mm length x 118mm width x 97mm depth with an 87mm invert
  • 7.38kg

Installation is easy and efficient with the interlocking process, saving you both time and effort. The sealant grove creates a watertight element, and the profile improves the speed of water and allows self-cleansing.

Standards & Certification

  • UKCA and CE marked and fully certified to Load Class A 15 BS EN 1433 2002

Dimensions

Length 1m Depth 97mm Width 118mm

Details

Material Concrete Product Type Channel Base and Grate Range RainDrain Load Rating A15

Downloads

There are no product downloads to show.

Questions & Answers

Question:

can you connect multiple lengths of this grate together to create a long run and if so, are the joins fully waterproof to avoid leaking at the joints?

Answer:

The channels can be connected to create a long run, however, they are not waterproof.

Upon installing them you would create a concrete trench so even if there's any water leakage it should be fine.

Question:

how do I select the grate? or is that sold separately?

Answer:

This comes with the galvanised grating. There are other 'get the look' gratings available to purchase as well.

Question:

Can the grating be removed for cleaning once in situ?

Answer:

Yes it can be taken on and off with relative ease.

Question:

Does this channel include the grate ? If so can you confirm which type?

Answer:

Yes this includes a grating, it is the galvanised A15 grating in the picture.

Question:

Are there fittings to connect this to the 110 underground pipe, do the plastic hex ones fit?

Answer:

This channel just has a 110mm knockout section on the bottom which you just push and silicone and plain end of 110mm pipe into.

Question:

Hi does this system do corner units?

Answer:

No, this system required you to cut the channel base at 45dg angles to form a corner by mitring them together.

Question:

Can you lift the grate on these without a special tool?

Answer:

You can lift these by using the lifting tool which is product code 1367 - or by using a screwdriver. The tool is not essential for lifting these.

Question:

What product is a replacement for the ACO Self?

Answer:

The ACO Self is no longer available, but this is code for the item that has replaced it: 38516 - Please note there is a slight size difference however, which can be seen on the product page for this item.
