Dimensions

Length: 500mm
Width: 123mm
Depth: 31mm
Weight: 1.2kg

Weight Class: C250

The ACO Building Drainage Modular 125 stainless steel linear drainage system is a further development of the highly successful Modular Channel system. Taking full advantage of the significant investment in state-of-the-art manufacturing plant, ACO Building Drainage now can offer an improved performance, fully flexible stainless steel drainage system suitable for most applications off the shelf.

• Fully tested and classified to BS EN 1433 - Drainage Channels for Vehicular & Pedestrian Areas
• CeMarking indicating that Modular 125 has met the Essential Requirements of BS EN 1433:
• Load bearing capacity
• Water tightness
• Durability
• Vee-bottomed profiled channel for enhanced flow efficiency at low flow rates
• Extended range of constant depth and sloping invert channels and accessories
• Wide range of gratings, available with loading class A15 to C250 and including unique optional grating security locks
• Vertical or horizontal gully option
• Standard range of components available from stock

Note: Modular 125 channel system is an off-the-shelf, stocked and manufactured in Grade 304 Stainless Steel.

Modular 125 is available in 316 grade stainless steel only to order.
