ACO Gully EG150 Stainless Steel 304 Telecopic Vertical Outlet

Code:
97296
Brand:

This EG150 Stainless Steel 304 with a telescopic vertical outlet is a great solution for various commercial projects. Part of the ACO Gully range, this gully features a top for mesh grating, works well with damp-proof membrane bonding and can serve as a foot-safe solution for ... Read More

£190.00 Incl. VAT
Earn points

SUPER Rewards Earn points and build more across our SUPERSTORES!

Find out more
Oops! Please select from the options
Est. Delivery: 3-5 Working Days
Shipping costs displayed in basket.
We can let you know when this product is back in stock.

This product is proving to be very popular and has unfortunately sold out.

Enter your email below and we'll notify you as soon as this product is back in stock:

For delivery Wednesday, Nov 13th - order in:
days hrs mins secs
Subject to stock availability, if products on a 24 hours service are ordered alongside products NOT on a 24 hours service, this may delay your whole order.
View Transport Policy

All delivery charges are included in the final shopping basket and are dependent on the products Scottish Highlands & the Islands where additional shipping charges will apply.

Please note that not all products will incur an additional delivery charge to the Scottish Highlands & the Islands – this is based on the costs from the manufacturer, distributor or courier providing shipping on our behalf. If your delivery address is in the Scottish Highlands and Islands, a member of our helpline team will contact you prior to processing your order should an additional delivery charge apply.

While we make every effort to ensure orders are delivered by the date required, we cannot guarantee availability from the manufacturer or the manufacturer's delivery schedules.

Any variation to web delivery date given will be advised to you by email or telephone. If we are unable to make delivery because access is not possible, we reserve the right to make a failed delivery charge.

Create a wishlist

"Flexible pipe work connections "

Paul Birch

Description

This EG150 Stainless Steel 304 with a telescopic vertical outlet is a great solution for various commercial projects. Part of the ACO Gully range, this gully features a top for mesh grating, works well with damp-proof membrane bonding and can serve as a foot-safe solution for standard pedestrian applications. With Load Class K3 to BS EN 1253 standards. Perfect for cementitious and tiled flooring applications.

Complete with a removable, in-line foul air trap (fitted as standard) this easy-to-clean gully features a smooth contour design to minimise bacteria traps. The telescopic height variant design also provides full 360° rotation and /- 7.5° pitch and roll adjustment. If you have concerns about the gully moving during its use, end stops are optional to prevent accidental dismantling. DPM bonding flanges are also provided to maintain sub-floor security.

Features & Benefits: ACO Gully EG150 Stainless Steel 304 Telecopic Vertical Outlet

  • Suitable for commercial applications in cementitious and tiled floors
  • K3 Load Class
  • 150mm x 150mm top size
  • 1.2l/s flow rate
  • 304-grade austenitic stainless steel fully compliant with BS EN 1253 standards
  • Slip-resistant with corrosion-resistant joints thanks to pickle passivation
  • Includes one-piece removable foul air trap for easy maintenance and cleaning
  • Height-adjustable levelling feet to save time installing
  • Bowl-shaped body deters silt and debris from collecting in corners for easy cleaning
  • Hygienic design including large radii formed contours, deep-drawn components and minimal welds to minimise crevices and bacteria traps according to BS EN 1672 and BS EN ISO 14159

Product Specification

  • Depth: 212mm - 242mm
  • Body Diameter: 357mm
  • Flow Rate: 1.2l/s
  • Spigot Diameter: 110mm
  • Weight: 1.85kg

Standards & Certification

  • Manufactured to BS EN 1253, BS EN 1672, BS EN ISO 14159

Dimensions

Length 150mm Width 150mm

Details

Material Stainless Steel Product Type Gully Weight Class A15 Gully Type Vertical
Floor Type Concrete Purpose Kitchen Type Commercial Application Kitchen
